Synology DiskStation DS224+ NAS

Compact data storage for edge deployments

Simply faster
DS224+ is faster at indexing files in Synology Drive and Synology Photos and more capable of running demanding web applications compared to previous-generation systems.1

Store, share, and protect
Manage all your documents, images, and other files, back up applications and devices, and protect your property with professional video surveillance.

Private cloud for data sharing

Hybrid work in the private cloud
Store, sync, access, and share data from any device, wherever you are. Work together seamlessly across different platforms, accessing files through mobile apps, desktop clients, or a browser-based interface. Quickly and easily roll back files in case of unwanted deletion or modification thanks to smart versioning.

CPU:  Model Intel Celeron J4125
System Memory 2 GB DDR4 non-ECC
Drive Bays 2 (3.5″ SATA HDD, 2.5″ SATA SSD)
External Ports
RJ-45 1GbE LAN Port 2
USB 3.2 Gen 1 Port* 2

Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1

Maximum Single Volume Size 108 TB
Maximum Internal Volume Number 64

Supported RAID Type
Synology Hybrid RAID
Basic
JBOD
RAID 0
RAID 1

Volume Expansion with Larger HDDs
Synology Hybrid RAID
RAID 1
Volume Expansion by Adding a HDD
Synology Hybrid RAID

Notes
Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.
Actual maximum storage pool and volume sizes depend on drive sizes used, the number of drive bays available, and the RAID configuration.
