The ASUS PRIME H610M-F WIFI D4 is an Intel® H610 LGA 1700 micro-ATX motherboard expertly engineered to unleash the full potential of 14th, 13th, and 12th Generation Intel® processors. It combines a robust power design, comprehensive cooling solutions, and intelligent tuning options, providing everyday users and PC DIY builders with reliable performance through intuitive software and firmware features.
Technical Specifications
CPU Support:
– Intel® Socket LGA1700 for Intel® Core™ 14th, 13th, and 12th Gen Processors, Intel® Pentium® Gold, and Celeron® Processors
– Supports up to Intel® 65W CPUs
– Chipset: Intel® H610 Chipset
Form Factor: Micro-ATX
Memory (RAM):
2 x DIMM slots supporting DDR4 memory
Expansion Slots:
– 1 x PCIe 4.0 x16 SafeSlot Core
– 1 x PCIe 3.0 x1 slot
Storage:
– 1 x M.2 2280 slot (PCIe 3.0 x4 mode, up to 32 Gbps)
– 2 x SATA 6Gb/s ports
Networking & Wireless:
– Realtek 1Gb Ethernet
– Wi-Fi 6
Rear I/O & USB Ports:
– 2 x HDMI™ ports
– 2 x USB 5Gbps ports (Type-A)
– 3 x USB 2.0 ports (1 x Type-A on rear, plus internal headers)
– 3 x Audio jacks
Internal Connectors:
– 2 x Front USB 5Gbps ports
– 2 x Front USB 2.0 ports
Intelligent Control & Energy Efficiency
– EPU (Energy Processing Unit): Automatically optimizes power consumption and maximizes energy savings via “Away mode,” which creates an extreme energy-saving scenario by shutting down unused I/O controllers.
– Digi+ VRM Control: Delivers real-time control over voltage droop, switching frequency, and power-efficiency settings.
UEFI BIOS
– Advanced Mode: Empowers complete control with an intuitive layout, a built-in Search Function to quickly locate specific settings, and ASUS User Profile to port configuration settings between different BIOS versions or share them with friends.
– EZ Mode: Offers intelligently simplified options for PC DIY beginners.
Cooling
– Hybrid Fan Headers & Multiple Temperature Sources: Each header can dynamically reference thermal sensors across the CPU and motherboard mapped via the UEFI BIOS to keep your rig cool under heavy workloads.
– PCH Heatsink: Provides thermal protection and stability for the chipset.
Performance & Connectivity
– PCIe® 4.0 Support: Designed for modern high-bandwidth GPUs, providing wide-load handling capabilities.
– Ultrafast M.2 Slot: Delivers data-transfer speeds up to 32 Gbps via PCIe 3.0 for faster OS and application load times.
Audio
– Outstanding Audio: Combined onboard features with dedicated Audio Shielding (separating analog and digital signal domains to reduce interference) and a Separate Layer for Left and Right Tracks to minimize crosstalk.
Customization & Software
– Armoury Crate: A centralized utility that gives you control of supported ASUS hardware settings, keyboard/mouse preferences, product registration, and community updates.
DIY Friendly & Protection
– Q-LED Core: Uses light patterns via the power LED during the Power-On Self-Test (POST) to help troubleshoot hardware issues:
– Fast blinking (4 Hz): No DRAM Detected
– 8Slow blinking (1/2 Hz): No VGA Detected
– Very slow blinking (1/8 Hz): No Boot Device Detected
– Solid light: Installation Completed
– SafeSlot Core: Fortified PCIe slot designed to prevent damage from heavy graphics cards.
– 5X Protection III: Multiple hardware safeguards ensuring all-round system durability and safety.
