XT Pro Ultra
Spacious, Powerful & Affordable
With new hardware releases demanding more cooling capacity and internal space, the XT-series is designed to deliver just that. And it delivers extremely good value. The length and width of the chassis easily fit even the largest graphics cards with space to spare for cable management. Cooling has been optimized with up to 10x 120 mm fan locations, support for 140 mm fans, and dedicated radiator space in the top of the chassis.
The XT-Series further innovates to bring support for the latest mainboards that host hidden connectors at the rear to unlock that zero-cable setup. The graphics card also benefits from 3x 120 mm fan locations on the mid-plate that provide direct cooling.
| Specifications | |
|---|---|
| General | |
| Model No. | PH-XT523P1_DBK01 |
| UPC Code | 886523303138 |
| Case Dimensions | 450 × 230 × 500 mm | 17.7 × 9.05 × 19.68 in |
| Form Factor | Mid-Tower |
| Mainboard Support | E-ATX* | ATX | Micro-ATX | Mini-ITX *Up to 280mm wide |
| Rear ATX Mainboard Support | MSI Project Zero | ASUS BTF | Gigabyte Project Stealth |
| Materials | Steel chassis | Tempered glass | ABS plastic |
| Side Window | Yes |
| PCI Slots | 7 |
| Vertical GPU Support | 3-slots (Riser cable sold separately) |
| Internal 2.5″ Bays | 5 + 1 × 3.5″ HDD |
| Internal 3.5″ Bays | 2 + 3 × 2.5″ SSD |
| Front I/O | |
| 1 × USB-C 3.2 Gen2 1 × USB 3.0 Microphone / Headphone combo Power Button Reset Button |
|
| Fans | |
| Total Fans | 120mm: 10x | 140mm: 6x |
| Top | 3x (120mm) | 2x (140mm) |
| Front | 3x (120mm) | 3x (140mm) |
| Rear | 1x (120mm) | 1x (140mm) |
| Midplate | 3x (120mm) |
| Radiator Support | |
| Top | Max. 360mm |
| Front | Max. 240mm |
| Rear | 120mm |
| Clearance | |
| CPU Cooler Height | 184 mm | 7.24 in |
| GPU Length | 415 mm | 16.33 in |
| GPU Width | 184 mm | 7.24 in |
| Power Supply Length | 270 mm | 10.62 in |
| Radiator Dimensions | |
| Top Radiator | 415 × 138 × 60 mm | 16.33 × 5.43 × 2.36 in |
| Front Radiator | 170 × 132 mm | 6.69 × 5.19 in |
| Side Radiator | – |
| Midplate Radiator | – |
| Extra | |
| Net Weight | 7.55 kg | 16.64 lbs |
| Gross Weight | 9.45 kg | 20.83 lbs |
| Scope of Delivery | 1 × XT Pro Ultra chassis 4 × M25-140 D-RGB fans |
| Accessory | 30 × Zip ties |
| Included Screws | 30 × Mainboard / SSD Screws 4 × Power Supply Screws 8 × HDD Screws 4 × Thumb Screws 12 × 30mm Fan Screws 1 × Motherboard Stand-off 1 × Stand-off Removal Tool |
