AMD RDNA 3 Architecture with Hardware Raytracing
The AMD RDNA 3 architecture features industry-advancing chiplet technology to deliver next-generation performance, visuals, and power efficiency. Discover new levels of performance with advanced AMD RDNA 3 compute units, featuring redesigned raytracing accelerators for incredible performance while improving image quality.
SPECIFICATIONS
GPU: AMD Radeon™ RX 7600 Graphics Card; AMD RDNA™ 3 Architecture
Engine Clock:
Boost Clock: Up to 2755 MHz
Game Clock: Up to 2355 MHz
Stream Processors: 2048
Compute Units: 32 CU
Infinity Cache: 32MB
Ray Accelerators: 32
Memory Size/Bus: 8GB/128 bit GDDR6
Memory Clock: 18 Gbps Effective
Displays: Maximum 4 Displays
Resolution: HDMI™: 7680×4320
DisplayPort 1.4: 7680×4320
Interface: PCI-Express 4.0 x8
Output: 1x HDMI; 3x DisplayPort
BIOS Support: UEFI
Game Index: 1080P Ultimate
Sapphire Features
– Fuse Protection
– Dual-X Cooling Technology
– Intelligent Fan Control
– Precision Fan Control
– Metal Backplate
– Two-Ball Bearing Fans
– Optimized Composite Heatpipe
– TriXX Supported
– TriXX Boost
AMD Features
– AMD RDNA 3 Architecture
– DirectX 12 Ultimate
– AMD Smart Access Memory
– AMD Infinity Cache
– PCI Express 4.0 Support
– AMD FreeSync™ Technology
– DisplayPort 1.4 with DSC
– HDMI
– Video Streaming up to 8K
– AMD Radeon VR Ready Premium
– AMD Radeon Image Sharpening
– AMD Radeon Anti-Lag
– AMD Software: Adrenalin Edition™ Technology
– Game Driver Optimizations
Cooling: 2 Fans
Form Factor: 2 slot, ATX
Dimension: 240(L)X 107.1(W)X 44.07 (H)mm
Power Consumption: 185W Total Board Power
OS: Linux®, Windows® 10, and Windows 11. 64-bit operating system required
System Requirement
– Minimum 550 Watt Power Supply
– 1 x 8-pin Power Connector.
– PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
– Minimum 8GB of system memory. 16GB recommended.
