Features
CONTACT FRAME FOR INTEL LGA1851 | LGA1700: Optimized contact pressure distribution for longer CPU life and better heat dissipation
ARCTIC’s P12 PRO FAN: More power at any speed – more powerful and quieter than the P12, especially at low speeds. Higher maximum speed for optimal cooling performance under high load
NATIVE OFFSET MOUNTING FOR INTEL AND AMD: Shifting the cold plate center towards the CPU hotspot ensures more efficient heat transfer
INTEGRATED VRM FAN: PWM-controlled fan that lowers the temperature of the voltage converters and thus ensures reliable performance
INTEGRATED CABLE MANAGEMENT: The PWM cables of the radiator fans are integrated in the sheathing of the hoses so that only a single visible cable is connected to the motherboard
Specifications
– TIM: MX-6 (0.8 g)
– Operating Ambient Temperature: 0—40 °C
– Pump: 800–2800 rpm (PWM controlled)
– Current | Voltage: 0.35 A | 12 V DC
– Cold Plate: Copper, Micro Skived Fins
– Tube Length: 450 mm
– Tube Diameter: Outer: 12.4 mm, Inner: 6.0 mm
– Weight: 2005 g
Compatibillity
– Intel: LGA1851, LGA1700
– AMD: AM5, AM4
Radiator
– Material: Aluminium
– Dimensions: 398 (L) x 120 (W) x 38 (H) mm
VRM Module
– VRM Fan: 400–2500 rpm (PWM-controlled)
– Current | Voltage: 0.05 A | 12 V DC
Radiator Fan
– General: 3x P12 Pro
– Speed: 600–3000 rpm
– Airflow: 77 cfm | 131 m³/h3/h
– Static Pressure: 6.9 mmH2O
– Bearing: Fluid Dynamic Bearing
– Current | Voltage: 0.33 A | 12 V DC
– Connector: 4-Pin Fan Plug
