Specifications
General Specifications
Motherboard Support up to E-ATX (285 mm wide)
Fan Support Top: 3×120 mm / 3×140 mm
Side: 3×120 mm / 3×140 mm (included)
Rear: 2×120 mm (included)
Radiator Support Top: 240 / 280 / 360 / 420 mm
Side: 240 / 280 / 360 / 420 mm
CPU Cooler up to 171 mm
PSU ATX up to 318 mm (200 mm with HDD Cage)
GPU up to 482 mm (337 mm with Side Radiator)
Front I/O USB-C (USB 3.2 Gen2x1 – 10 Gbps)
2× USB-A (USB 3.2 Gen1x1 – 5 Gbps)
3.5 mm Line-In/Out
Power Button
Warranty 6 Years
Operating Ambient Temperature 0–40 °C
Net Weight 15.4 kg
Volume 64 l
Dimensions 529 × 231 × 529 mm
Drive Bays Behind Tray: 3× 2.5″
HDD Cage: 2× 3.5″ or 2.5″ + 1× 2.5″
PCI Slots 7
Cable Management Space 35 mm
Dust Filters Top, Right Side
PSU RGB Stripe Specifications
LEDs 24 × A-RGB Gen 2
Current / Voltage 0.89 A / 5 V DC
Connector 3-Pin A-RGB Plug + Socket
Fan Specification – P12 Pro A-RGB (Rear, 2×)
Speed 600–3000 rpm
Air Flow 77 cfm | 131 m³/h
Static Pressure 6.9 mmH₂O
Bearing Fluid Dynamic Bearing
Current / Voltage 0.33 A / 12 V DC
Connector 4-Pin Fan Plug + Socket
RGB LEDs 12× A-RGB Gen 2, 0.40 A / 5V
Fan Specification – P14 Pro Reverse A-RGB (Side, 3×)
Speed 400–2650 rpm
Airflow 98 cfm | 166.5 m³/h
Static Pressure 5.1 mmH₂O
Bearing Fluid Dynamic Bearing
Current / Voltage 0.40 A / 12 V DC
Connector 4-Pin Fan Plug + Socket
RGB LEDs 12× A-RGB Gen 2, 0.40 A / 5V
