MSI MPG A850G PCIE5 Modular 850W 24-Pin ATX Power Supply Unit

MPG A850G PCIE5

• Supports Nvidia® GeForce RTXTM 40 Series graphics cards
• Full modular design
• Flat cables
• 80 Plus Gold certified for high efficiency
• 100% all Japanese 105oC capacitor
• Active PFC design
• Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
• LLC Half Bridge Topology with DC-DC module design

Specifications

Efficiency Rating: 80 PLUS Gold (up to 90%)

Modular: Yes (full modular)

Fan Size: 135 mm

Fan Bearing: Fluid Dynamic Bearing

Dimensions (DxWxH): 150 x 150 x 86 mm

PFC Type: Active PFC

Input Voltage Range: 100-240

Power Watt: 850W

Power Excursion: 1700W (*up to 200% of the PSU’s rated power for 100μs)

Input Frequency Range: 50~60 Hz

Protection: OCP / OVP / OPP / OTP / SCP / UVP

ATX (24 pin): 1

EPS (4+4 pin): 2

PCI-E 5.0 (16 pin): 1 (600W)

PCI-E (6+2 pin): 6

SATA (15 pin):  8

PERIPHERAL (4 pin): 4

FDD (4 pin): 1
