Capacitors and chokes pass demanding tests to achieve Military-grade Certification.
Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
A protective PCB coating protects against moisture, dust, and extreme temperatures.
An 80 Plus Gold Certification is the result of Japanese capacitors and other premium components.
Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
Fully modular etched cables keep your rig neat and tidy.
Specification:
- Model TUF Gaming: 1000W Gold
- Intel Form Factor: ATX12V
- PFC Type: Active PFC
- ATX Standard: ATX 3.0
- Dimensions: 150 x 150 x 86 mm
- Efficiency: 80Plus Gold
- MTBF: >120,000 hrs @ 40°C
- Protection Features: OPP/OVP/UVP/SCP/OCP/OTP
- Hazardous Materials: ROHS
- AC Input Range: 100-240Vac
- DC Output Voltage: +3.3V +5V +12V -12V +5Vsb
- Maximum Load: 25A25A83.3A 0.8A 3A
- Combined Load: 130W 130W 1000W 9.6W 15W
- Total Output: 1000W
- Cable Connectors:
- MB 24/20-pin x 1
- CPU 4+4-pin x 2
- PCI-E 16-pin x 1 (both PSU & component side)
- PCI-E 8-pin x 4
- SATA x 5
- PERIPHERAL x 4
- Package Contents :
- Power Cord x 1
- Motherboard Power Cable x 1 (610mm)
- CPU Cable x 2 (650mm)
- PCI-E Gen 5 16-pin Cable x 1 (675mm)
- PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (675mm)
- PCI-E 1-to-1 Cable x 2 (675mm)
- SATA 1-to-2 Cable x 1 (400+120mm)
- SATA 1-to-3 Cable x 1 (400+120+120mm)
- Peripheral 1-to-4 Cable x 1 (400+150+150+150mm)
- TUF Gaming Cable Tie x 3
- User Manual x 1
- Weight: 2.48kg (single PSU)
- 0dB Technology: Supported. The fan shuts off entirely when the PSU is under certain load
- 0dB Fan Button: No. The product operates in 0dB mode by default. The fan will only spin up when the system reaches a certain load.
