SPECIFICATIONS:
Model : TUF-GAMING-750G-EVO | TUF-GAMING-850G-EVO
Intel Form Factor: ATX12V
PFC Type: Active PFC
ATX Standard: ATX 3.1
80 PLUS Efficiency: 80Plus Gold
Cybenetics Efficiency: Platinum (230V) ; Gold (115V)
Protection Features: OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials: ROHS
AC Input Range: 100-240Vac
DC Output Voltage: +3.3V +5V +12V -12V +5Vsb
Maximum Load: 20A 20A 62.5A 0.3A 3A
Combined Load: 110W 110W 750W 3.6W 15W
Total Output: 750W
Cable Connectors:
-MB 20+4pin x 1
-CPU 4+4pin x 2
-PCI-E 16pin x 1 (12V-2×6)
-PCI-E 6+2pin x 2
-SATA x 4
-PERIPHERAL x 2
Package Contents
-Power Cord x 1
-Motherboard Power cable x 1 (610mm)
-CPU 1-to-2 Cable x 1 (650mm+100mm)
-PCI-E Gen 5.1 Cable (16-pin-to-16-pin) x 1 (500mm)
-PCI-E 1-to-2 Cable (8-pin-to-6+2pin*2) x 1 (500+100mm)
-SATA & Peripheral 1-to-2+1 Cable x 2 (400+120+120mm)
-TUF Gaming Cable Tie x 3
-User Manual x 1
-Motherboard Power cable x 1 (610mm)
-CPU 1-to-2 Cable x 1 (650mm+100mm)
-PCI-E Gen 5.1 Cable (16-pin-to-16-pin) x 1 (500mm)
-PCI-E 1-to-2 Cable (8-pin-to-6+2pin*2) x 1 (500+100mm)
-SATA & Peripheral 1-to-2+1 Cable x 2 (400+120+120mm)
-TUF Gaming Cable Tie x 3
-User Manual x 1
Dimensions: 140 x 150 x 86 mm
Weight: 1.32 kg (single PSU)
