The G700 Gold consists of dependable power supply units for entry level users and system integrators.
The Cooler Master G700 Gold 80 PLUS Gold MPW-7001-ACAAG-U2 power supply boasts a combined power of 700W and 90% efficiency. It features peripheral power connectors (Molex) and PCI Express power connectors (6+2 pin). Featuring HDB bearing technology and power protection functions against various eventualities. Its power factor correction is active and it is 80 PLUS Gold certified. The design includes a 12cm fan for active cooling. Compatible with PCs and servers, and featuring an ATX form factor, it’s a reliable choice for systems requiring a stable power supply.
SPECIFICATION
ErP 2014 Lot 3: Yes
Operating Temperature: 0-40°C
PFC: Active PFC
ATX 24 Pin Connectors: 1
EPS 4+4 Pin Connectors: 1
Power Good Signal: 100 – 150 ms
EPS 8 Pin Connector: 1
80 PLUS Rating: 80 PLUS Gold
Fan Size: 120mm
Category: 500 to 750W
MTBF: >100,000 Hours
Input Frequency: 47-63Hz
80 PLUS Rating: Gold
Modular: Non Modular
Fan Bearing: HDB
Input Voltage: 100-240V
PCI-e 6+2 Pin Connectors: 4
SATA Connectors: 6
Peripheral 4 Pin Connectors: 3
Protections: OVP
ATX Version: ATX 12V V2.52
Protections: OPP
Protections: SCP
Dimensions (L x W x H): 140 x 150 x 86 mm
Protections: UVP
Protections: OTP
Protections: OCP
Series: G Series
Regulatory: CCC
Input Current: 10-5A
Regulatory: CE
Regulatory: EAC
Efficiency: ≥90% @ Typical Load
Regulatory: cTUVus
Regulatory: FCC
Hold Up Time: ≥15ms at 100% load
Regulatory: BSMI
Regulatory: CB
Regulatory: TUV
Regulatory: RoHS2.0
Regulatory: KC+KCC
Regulatory: BIS
Model: MPW-7001-ACAAG
