Specification
GPU Engine Specs
CUDA Cores: 4608
Boost Clock (MHz): 2602MHz
Base Clock (MHz): 2235MHz
Thermal and Power Spec
Minimum System Power Requirement (W): 650W
Supplementary Power Connectors: 1x PCIe 8-pin cables
Memory Specs
Memory Clock: 28Gbps
Standard Memory Config: 16GB
Memory Interface: GDDR7
Memory Interface Width: 128-bit
Memory Bandwidth (GB/sec): 448 GB/sec
Feature Support
Real-Time Ray Tracing: Yes
Ray Tracing Cores: 4th Generation, 72 TFLOPS
Tensor Cores: 5th Generation, 759 AI TOPS
NVIDIA Architecture: Blackwell
Microsoft DirectX: 12 Ultimate
NVIDIA DLSS: 4
NVIDIA Ansel: Yes
NVIDIA FreeStyle: Yes
Bus Support: PCI Express Gen 5
NVIDIA ShadowPlay: Yes
OS Certification: Windows 11, Linux, FreeBSDx86
NVIDIA Highlights: Yes
NVIDIA G-SYNC™-Ready: Yes
Game Ready Drivers: Yes
NVIDIA Studio Drivers: Yes
NVIDIA GPU Boost™: Yes
Vulkan API: 1.4
OpenGL: 4.6
NVIDIA Encoder: 1x Ninth Generation
NVIDIA Decoder: 1x Sixth Generation
Accessories
Graphics Card Dimensions
Length: 250mm
Height: 116mm
Width: 41mm
Display Support
Multi Monitor: up to 4
Maxmium Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC
HDCP: 2.3
Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b
