INNO3D GeForce RTX 5060 Twin X2 OC 8GB GDDR7 Graphics Card

The INNO3D GeForce RTX 50 Series promises exceptional performance from these next-gen graphics cards powered by Nvidia’s Blackwell architecture. The INNO3D GeForce RTX 5060 TWIN X2 OC is a compact powerhouse designed for space-conscious enthusiasts, featuring a sleek dual-slot design that seamlessly integrates into smaller form factor builds. The TWIN X2 OC doesn’t just set new standards in performance; it also captivates with its contemporary aesthetic. This GPU features 4,608 CUDA cores and 8GB GDDR7 memory with a 128-bit interface, and a boost clock of 2,527MHz providing ample power for high-resolution gaming and demanding applications. Redefining the balance between style, size, and raw power, this next-generation graphics card establishes itself as the new benchmark, seeking uncompromised visual excellence in a compact package.

Specification

GPU Engine Specs
CUDA Cores:  3840
Boost Clock (MHz):  2497MHz
Base Clock (MHz):  2280MHz

Thermal and Power Spec
Minimum System Power Requirement (W):  550W
Supplementary Power Connectors:  1x PCIe 8-pin cables

Memory Specs
Memory Clock:  28Gbps
Standard Memory Config:  8GB
Memory Interface:  GDDR7
Memory Interface Width:  128-bit
Memory Bandwidth (GB/sec):  448 GB/sec

Feature Support
Real-Time Ray Tracing:  Yes
Ray Tracing Cores:  4th Generation, 58 TFLOPS
Tensor Cores:  5th Generation, 614 AI TOPS
NVIDIA Architecture:  Blackwell
Microsoft DirectX:  12 Ultimate
NVIDIA DLSS:  4
NVIDIA Ansel:  Yes
NVIDIA FreeStyle:  Yes
Bus Support:  PCI Express Gen 5
NVIDIA ShadowPlay:  Yes
OS Certification:  Windows 11 / 10, Linux, FreeBSDx86
NVIDIA Highlights:  Yes
NVIDIA G-SYNC™-Ready:  Yes
Game Ready Drivers:  Yes
NVIDIA Studio Drivers:  Yes
NVIDIA GPU Boost™:  Yes
Vulkan API:  1.4
OpenGL:  4.6
NVIDIA Encoder:  1x Ninth Generation
NVIDIA Decoder:  1x Sixth Generation

Accessories
Length:  225mm
Height:  116mm
Width:  41mm
Display Support
Multi Monitor:  up to 4
Maximum Digital Resolution:  4K at 480Hz or 8K at 165Hz with DSC
HDCP:  2.3
Standard Display Connectors:  3x DisplayPort 2.1b, 1x HDMI 2.1b
