ATX 3.1 Ready
It has an output port that is compliant with PCIe 5.1 and Intel PSDG(Power Supply Design Guide) ATX 3.1, also the MAG A750GL PCIE5 power supply can hold up to 2x total power excursion and 3x GPU power excursion.
LEVEL UP YOUR GAME
With native 16 PIN PCIe connector this power supply is ready for NVIDIA@ GeForce RTE 40 Series graphics cards. It can freely pipe up to 450W of power to PCIe 5.1 graphics cards.
DUAL-COLOR 16-PIN CABLE
The 16 Pin PCIe cable’s connector color has been changed to yellow so that users can easily see if the connector has been plugged in properly. Besides, the patented pending Dual-color 16-pin cabledual-color also won Wccftechawards in the 2023 COMPUTEX
ENERGY EFFICIENCY CERTIFICATION
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS Gold certification promises lower energy consumption and higher efficiency.
COMPACT SIZING
Smaller than typical PSUs on the market, this power supply unit that can save space and make it easier to organize cables in the computer case by freeing up more room inside.
ONLY WHAT YOU NEED
The connectors that required by the build need to be used, significantly reducing cable clutter and simplifying the system’s overall build. Additionally, the included cable pack provides a storage solution for any unused cables.
ALL THE MORE ORGANIZED
Organizing cables is often the most bothersome part of building a PC. The flat cables make cable management easier and less of headache! Thanks to the flat cables, the entire system can be more organized and has more room for unobstructed airflow.
FLUID DYNAMIC BEARING
The power supply’s fan sports a fluid dynamic bearing that perfectly balances cooling performance and noise level.
DC to DC & Full bridge
DC to DC and Full bridge be combined to achieve higher conversion efficiency, stable output voltage, and quick voltage adjustment for different usage scenarios, thus providing a stable power supply design.
Specification:
Efficiency Rating 80 PLUS Gold (up to 90%)
Modular Yes (full modular)
Fan Size 120 mm
Fan Bearing Fluid Dynamic Bearing
Dimensions (DxWxH) 140 x 150 x 86 mm
PFC Type Active PFC
Input Voltage Range 100~240 VAC
Power Watt 750W
Power Excursion 1500W (*up to 200% of the PSU’s rated power for
100μs)
Input Frequency Range 47-63Hz
Protection OCP / OVP / OPP / OTP / SCP / UVP
ATX (24 pin) 1
EPS (4+4 pin) 2
PCI-E 5.0 (16 pin) 1 (450W)
PCI-E (6+2 pin) 3
SATA (15 pin) 8
MOLEX (4 pin) 4
FDD (4 pin) 1
