Key Features
Lightning Fast Experience: Features PCIe 4.0 and Lightning Gen4 x4 M.2 solution with up to 64GB/s bandwidth for maximum transfer speeds.
Core Boost: Combines a premium layout and digital power design to support more cores, deliver faster/undistorted current delivery to the CPU at pin-point precision, and provide ideal conditions for CPU overclocking.
DDR4 Boost: Fully isolated DDR circuit to deliver pure data signals for the best performance and stability (supports DDR4 Memory up to 4600(OC) MHz).
2oz Thickened Copper PCB: Enhanced PCB design that improves heat dissipation and performance reliability.
Audio Boost: Studio-grade sound quality for an immersive audio experience.
4K Support: Onboard HDMI™ supporting up to 4K UHD resolution.
Fully Fan Control: Manage speeds and temperatures for all system and CPU fans using a simplified graphical interface with up to 4 temperature targets.
Dragon Center: A brand-new software integrating all MSI exclusive tools with a user-friendly interface.
Technical Specifications
Socket: AMD Socket AM4
Chipset: AMD® B550 Chipset
Form Factor: mATX
Memory Channel: Dual
DIMM Slots: 2
Max Memory (GB): 64
PCI-E x16: 1
PCI-E Gen: Gen4 / Gen3
PCI-E x1: 1
SATAIII: 4
M.2 Slot: 1
RAID: 0/1/10
TPM (Header): 1
USB 3.2 Ports (Front): 2 (Gen 1, Type A)
USB 3.2 Ports (Rear): 4 (Gen 1, Type A)
USB 2.0 Ports (Front): 4
USB 2.0 Ports (Rear): 2 (Type A)
Serial Ports (Front): 1
Audio Ports (Rear): Realtek® ALC892/ALC897 Codec
DVI-D: 1
HDMI: 1
DirectX: 12
CPU Support: Support for AMD Ryzen™ 5000 & 3000 Series, 4000 G-Series desktop processors
