- B850 GAMING PLUS WIFI6E
– Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
– Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
– Ultra Performance: 12+2+1 Duet Rail Power System with P-PAK, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper PCB
– Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
– High-speed Connectivity: 2.5G LAN with Wi-Fi 6E Solution – The premium solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
– Lightning Fast Game experience: PCIe 4.0 slots, Lightning Gen 5 x4 M.2, Front USB Type-C
– EZ DIY: EZ PCIe Clip II, EZ M.2 Clip II, EZ-Conn Design and EZ Antenna
– Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience - Key Features
1. Ultra Performance & Power Solution
Processor Support: Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors.
Power System: 12+2+1 Duet Rail Power System with P-PAK, dual 8-pin CPU power connectors, Core Boost, and Digital Power.
PCB Design: 6-layer PCB made by 2oz thickened copper for higher bandwidth and reliable circuit transmission.
Overclocking & Performance Tuning: Features Game Boost (one-click CPU overclocking), AI Boost (NPU overclocking), EXPO / A-XMP memory profiles, Performance Preset (PBO Auto/Enable), and PBO Thermal Profiles (85°C, 75°C, 65°C).
2. Cooling & Thermal Design (Frozr Guard)
Extended Heatsink: Enlarges the surface of heat dissipation to maintain heavy load performance.
Thermal Pads: MOSFET thermal pads rated for 7W/mK and additional choke thermal pads.
M.2 Shield Frozr: Strengthened thermal solution to keep M.2 SSDs safe and performing at high levels.
Frozr AI Cooling: Automatically adjusts system fan duties based on CPU and GPU temperatures.
3. Memory Support & Boost
DDR5 Support: Dual Channel DDR5 memory support up to 8200+ MT/s (OC) with dedicated SMT welding and Memory Boost technology.
High-Efficiency Mode: Optimizes memory performance by increasing bandwidth and reducing latency via customizable RAM timing settings.
Latency Killer: Reduces memory latency by up to 12% when running at high frequencies (compatible with AGESA 1.2.0.2b and later).
4. High-Speed Connectivity
Networking: 2.5G LAN paired with a Wi-Fi 6E Solution, managed via the AI LAN Manager for optimized traffic and low latency.
Storage: Equipped with a Lightning Gen 5 x4 M.2 slot (128 Gbps) and a Lightning Gen 4 M.2 slot (64 Gbps) with M.2 Shield Frozr.
Expansion & USB: PCIe 4.0 slots with Steel Armor support, front USB Type-C, and rear/front high-speed USB ports.
5. EZ DIY & Assembly Features
EZ M.2 Installation: EZ M.2 Clip II and EZ M.2 Clip II Remover for toolless SSD installation and repositioning.
EZ GPU Installation: EZ PCIe Clip II on the first slot featuring a rebounding force mechanism for easy removal with one finger.
Smart Assembly: Pre-installed I/O Shield, EZ Antenna with magnetic stand, EZ Conn-Design (JAF_1 header for ARGB and fan integration), and Driver Utility Installer.
Troubleshooting: EZ Debug LED, EZ Memory Detection LED, Flash BIOS Button, and Clear CMOS Button.
6. Audio & Experience
Audio Boost: High definition audio processor, high-quality audio capacitors, dedicated audio jacks, isolated audio signal, de-pop protection, and an Isolated Analogy Structure to keep voice crisp.
Mystic Light: Customizable RGB lighting with Million colors, fancy LED effects, and Mystic Light Extension pin headers (A-Rainbow V2 and RGB support).
Click BIOS X: A user-friendly graphical interface offering both EZ Mode and Advanced Mode with features like Hardware Monitor, M-Flash, U-Key, and Search.
MSI Center: A centralized software suite integrating AI Engine, Mystic Light, True Color, User Scenario, and Cooling Wizard.
Specifications
CPU Support: AMD Ryzen™ 9000, 8000, and 7000 Series Desktop Processors (AM5 socket)
Memory: Dual Channel DDR5, up to 8200+ MT/s (OC)
Power Architecture: 12+2+1 Duet Rail Power System (Vcore 12-phase, SOC 2-phase, MISC 1-phase) with dual 8-pin power connectors
PCB Construction: 6-layer PCB with 2oz thickened copperExpansion Slots:
PCIe 4.0 slots with Steel Armor
Lightning Gen 5 x4 M.2 slot
Lightning Gen 4 M.2 slot
Networking: 2.5G LAN, Wi-Fi 6E Solution, and EZ Antenna
Cooling Features: Extended Heatsink, 7W/mK thermal pads, EZ M.2 Shield Frozr II, Combo Fan Headers (Pump/Sys Fan auto-detect)
Audio: Audio Boost with Isolated Analogy Structure and high-quality audio capacitors
BIOS & Software: Click BIOS X (EZ/Advanced modes), MSI Center with AI Engine and Mystic Light
Sold OutNew
MSI B850 GAMING PLUS WiFi6E AM5 ATX DDR5 PCIe 5.0 2.5G LAN Gaming Motherboard
₱12,495.00
Out of stock
