Honeywell PTM7950 TIM
The Honeywell PTM7950 Thermal Interface Material (TIM) offers a premium solution for high-performance electronics, particularly in the demanding field of graphics processing units (GPUs). The PTM7950 delivers superior thermal conductivity, enhancing the reliability and longevity of graphics cards by its outstanding material characteristics.
Free Flow
The Free Flow cooling design is tailored for axial fan systems, featuring an advanced heatsink fin module that optimizes airflow paths. By reducing turbulence and channeling air efficiently, it maximizes heat dissipation, ensuring consistent performance even under heavy thermal loads.
Core Performance
- Boost Clock: Up to 3290 MHz
- Game Clock: Up to 2700 MHz
- Stream Processors: 2048
- Compute Units: 32 CUs (featuring 3rd Gen RT + 2nd Gen AI Accelerators)
- Infinity Cache: 32MB
- Ray Accelerators: 32
- AI Accelerators: 64
Memory
- Memory Size / Bus: 16GB / 128-bit GDDR6
- Memory Clock: 20 Gbps Effective
Display & Connectivity
- Maximum Displays: 3
- Resolution Support:
- HDMI: 7680×4320
- DisplayPort 2.1a: 7680×4320
- Interface: PCI-Express 5.0 x16
- Output Ports:
- 2x HDMI®
- 1x DisplayPort™ 2.1a
- BIOS Support: UEFI
Gaming Focus
- Game Index: Optimized for 1440p gaming
Sapphire Exclusive Features
- Thermal Interface Material: Honeywell PTM7950
- Cooling: Dual-X Cooling with AeroCurve Fan Blade, Free Flow, Integrated Cooling Module
- PCB: High TG Copper PCB
- Heatpipes: Optimized Composite Heatpipes
- Backplate: Metal Backplate
- Fan Bearings: Two-Ball Bearing Fans
- Power Design: 9-Phase Digital Power Design
- Protection: Fuse Protection
- Fan Control: Intelligent Fan Control, Precision Fan Control
- Software Support: TriXX Supported, TriXX Boost, Performance vs. Efficiency Quicksets, Glow!
- RGB Support: External RGB LED MB Sync, ARGB SAPPHIRE Logo
- Accessories: 3pin 5V ARGB Cable
AMD Features & Technologies
- AMD HYPR-RX with AFMF 2
